Atmospheric Reactor
Tanlet atmospheric stainless hlau reactor rau batch tshuaj tiv thaiv, sib tov, cua sov, thiab cua txias nyob rau hauv atmospheric los yog ze ntawm - atmospheric tej yam kev mob - configurable nrog thauj tog rau nkoj / ncej agitators, cua sov / txias tsho, thiab kev cai sib txuas - haum rau cov kws tshuaj intermediates, zoo tshuaj, kev kho ib puag ncig, thiab slurry.
Technical Parameter
|
Model thiab specification |
WJG 300 |
WJG 400 |
WJG 500 |
WJG 600 |
WJG 1000 |
WJG 2000 |
WJG 3000 |
WJG 5000 |
|
Jacket Siab (MPa) |
Tsawg dua lossis sib npaug li 0.2 MPa / Tsawg dua lossis sib npaug li 0.3 MPa |
|||||||
|
Lub cev muaj zog (Kw) |
0.55 |
0.55 |
0.75 |
0.75 |
1.1 |
1.5 |
1.5 |
2.5 |
|
Txoj kab uas hla (mm) |
900 |
1000 |
1150 |
1150 |
1400 |
1500 |
1700 |
2000 |
|
Tank Qhov siab (mm) |
1800 |
1900 |
2200 |
2300 |
2600 |
2900 |
3200 |
3700 |
|
Nco tseg: Cov kev txwv saum toj no yog cov ntaub ntawv kwv yees thiab yuav raug kho raws li tus neeg siv khoom tsim tshwj xeeb. |
||||||||
Agitator Configuration rau cov khoom sib txawv
Lub agitator yog ib qho tseem ceeb tshaj plaws ntawm lub atmospheric reactor - kev sib xyaw ua haujlwm ncaj qha cuam tshuam rau cov tshuaj tiv thaiv sib xws. Peb teeb tsa cov txheej txheem sib txawv raws li koj cov khoom siv thiab cov kev xav tau ntau lawm:
Anchor Agitator:Tsim nyog rau cov ntaub ntawv viscous thiab cov ntawv thov uas kaw - rau - kev sib xyaw phab ntsa yog qhov tseem ceeb.
Frame Agitator:Muab kev sib xyaw dav dav hauv lub nkoj - zoo tagnrho rau kev sib xyaw ua ke thiab cov txheej txheem tshuaj tiv thaiv uas xav tau cov khoom siv sib xws.
Customized Agitation:Rau siab dua - cov ntaub ntawv viscosity, tshem tawm cov khib nyiab, lossis cov kev xav tau tshwj xeeb sib xyaw, cov qauv kev sib cav thiab kev tsav tsheb tuaj yeem raug kho raws li koj cov ntaub ntawv txheej txheem.
Kev tswj qhov kub thiab txias yam tsis muaj kev kub ntxhov
Ntau qhov kev tawm tsam huab cua tseem xav tau kev tswj xyuas kom raug thermal. Lub tshuab hluav taws xob tuaj yeem nruab nrog lub tsho sab nraud rau cov cua kub cua sov lossis cua txias tawm, tso cai rau lub nkoj kub hloov raws li koj cov txheej txheem ntau lawm.
Tej configurations muaj xws li:
- Cua sov dej ncig
- Kev khiav dej txias
- Thermal kua ncig
- Chav{0}} cua sov raws li qhov muaj feem tau
- Rwb thaiv tsev rau kev txhim kho thermal efficiency
- Kev ntsuas kub thiab tswj cov khoom
Jacket siab xaiv ntawm Tsawg dua los yog sib npaug rau 0.2 MPa los yog Tsawg dua los yog sib npaug rau 0.3 MPa muaj, nrog rau qhov kawg tsim txiav txim siab los ntawm koj cov txheej txheem yuav tsum tau ua.
Ua rau Batch ntau lawm thiab yooj yim cov khoom pov tseg
Rau batch ntau lawm, lub reactor xav tau kev txhawb nqa ntau dua li cov tshuaj tiv thaiv nws tus kheej. Cov cuab yeej tuaj yeem teeb tsa nyob ib puag ncig ntawm kev ua haujlwm tiav:
Kev them nyiaj → Sib tov → Cua sov / txias → Cov tshuaj tiv thaiv → Sampling → Discharge → Tu
Lub nkoj tsim muaj xws li lub cev lub cev, lub taub hau elliptical, agitator, lub tsho, kev txhawb nqa qauv, tsav sib dhos, thiab cov ncej sealing system. Cov khoom specifications thiab nozzle npaj tuaj yeem kho raws li koj cov txheej txheem yuav tsum tau ua.
Cov ntaub ntawv thiab cov khoom siv -Contact Construction
Kev xaiv cov khoom siv yuav tsum yog raws li cov yam ntxwv ntawm cov txheej txheem nruab nrab, kev tu thiab kev ua haujlwm yuav tsum tau ua.
Cov kev xaiv zoo tshaj plaws stainless hlau muaj xws li:
- SS304 - Haum rau dav dav - lub hom phiaj ua ib puag ncig
- SS316L - Nyiam qhov twg muaj kev tiv thaiv corrosion ntau dua lossis cov khoom xav tau ntau dua - yuav tsum muaj kev tiv tauj
- Lwm cov ntaub ntawv - Muaj rau cov kev cai tshwj xeeb ntawm kev sib raug zoo tshuaj lom neeg raws li kev tshuaj xyuas engineering
Quality & Cov ntaub ntawv
Rau qhov project-raws li kev txiav txim, Tanlet tuaj yeem muab cov ntaub ntawv thev naus laus zis thiab zoo rau cov neeg siv khoom tshuaj xyuas, txhawb nqa kev pom zoo kos duab, tshuaj xyuas thiab kev lees paub cov khoom siv.
GA kos duab thiab txheej txheem kev sib txuas lus qhia
Cov ntaub ntawv pov thawj rau cov khoom lag luam -cov khoom tiv tauj
Vuam thiab soj ntsuam cov ntaub ntawv
Cov ntaub ntawv ntsuas siab
Factory Acceptance Test (FAT) cov ntaub ntawv
Kev khiav hauj lwm & tu phau ntawv
FAQ
Q: Dab tsi kev lag luam siv Atmospheric Reactors?
A: Lawv feem ntau yog siv hauv cov tshuaj intermediates, tshuaj zoo, kev tiv thaiv ib puag ncig thiab lwm yam khoom siv sib xyaw ua ke -cov ntawv thov uas suav nrog kev sib xyaw thiab tswj cov tshuaj tiv thaiv.
Q: Lub reactor puas tuaj yeem kho tau?
A: Yog. Tanlet tuaj yeem hloov kho cov khoom siv hauv nkoj, kev teeb tsa lub taub hau, kev teeb tsa agitator thiab lwm yam khoom siv tshwj xeeb raws li tus neeg siv khoom xav tau.
Q: Kuv puas tuaj yeem xaiv ntau hom agitator?
A: Yog. Thauj tog rau nkoj thiab ncej agitators yog cov configurations siv rau no reactor series. Qhov kawg agitator yuav tsum raug xaiv raws li viscosity, solids cov ntsiab lus thiab kev sib xyaw.
Q: Lub sij hawm ua tus txheej txheem ntau lawm yog dab tsi?
A: Rau cov txheej txheem kev hloov kho reactor, lub sijhawm ua haujlwm raug cai yog 30-45 hnub tom qab tso nyiaj thiab cov kev qhia tshwj xeeb kawg tau lees paub. Lub sijhawm tiag tiag tau lees paub thaum pom kev kos duab.
Q: Cov nqe lus them nqi twg koj txais?
A: T / T yog tus qauv kev them nqi. L / C tuaj yeem sib tham rau kev tsim nyog thoob ntiaj teb kev txiav txim, raws li tus nqi xaj thiab daim ntawv cog lus.
Q: Tanlet puas tuaj yeem muab kev teeb tsa txawv teb chaws?
A: Yog. Tanlet muab kev teeb tsa thiab kev cob qhia txawv teb chaws rau cov khoom siv ua haujlwm thaum xav tau.
Q: Lub sijhawm lav yog dab tsi?
A: Lub sijhawm lav tus qauv hais los ntawm Tanlet yog 1 xyoos.
Cim npe nrov: Tuam Tshoj atmospheric reactor manufacturers, lwm tus neeg, Hoobkas
